In the global pursuit of energy conservation, emission reduction and sustainable urban development, LED street lights have gradually replaced traditional high-pressure sodium lamps and become the core of urban road lighting systems. Thanks to their advantages of high luminous efficiency, long service life, good dimmability and environmental protection, LEDs have brought a revolutionary upgrade to road lighting. However, the light emitted by LED chips is naturally scattered with uneven distribution and large beam angles. Without effective optical control, it is difficult to meet the strict requirements of road lighting for illuminance uniformity, glare control and light utilization efficiency. Secondary optics design, as a key link in optimizing LED street light performance, has become the core focus of improving lighting quality and realizing energy conservation goals.
Secondary optics refers to the process of redistributing and controlling the light emitted by LEDs through external optical components (such as lenses, reflectors, etc.) on the basis of primary optics (encapsulation design to maximize light extraction from chips). Its core purpose is to concentrate light on the required lighting area, reduce invalid light scattering, optimize light distribution curves, and finally achieve the balance between high lighting quality and low energy consumption. This article will detail the key matching skills of LED street light secondary optics, covering component selection, scheme design, scene adaptation and common problems solving, to provide practical guidance for engineering applications and product optimization.
1. Clarify Core Requirements: The Premise of Secondary Optics Matching
Before carrying out secondary optics matching, it is necessary to clarify the core requirements of road lighting, which directly determines the direction of optical design. The key indicators to focus on include the following aspects:
Illuminance and Uniformity: According to the road grade (arterial road, secondary arterial road, branch road, sidewalk), refer to international standards (CIE) and local specifications (such as CJJ 45-2015) to determine the required average illuminance and uniformity (usually the ratio of minimum illuminance to average illuminance U1 ≥ 0.4). For example, urban arterial roads require higher average illuminance (20-30 lx) and uniformity to ensure driving safety, while sidewalks can appropriately reduce the standard (5-10 lx).
Glare Control: Glare from street lights will seriously affect the visual comfort of drivers and pedestrians, and even cause potential safety hazards. It is necessary to control the light intensity in the horizontal and upward directions through secondary optics, and select appropriate cut-off types (full cut-off, semi-cut-off, non-cut-off) according to the scene.
Light Utilization Efficiency: The core goal of secondary optics is to reduce light loss. The light emitted by LEDs should be concentrated on the road surface as much as possible, avoiding scattering to the sky or surrounding irrelevant areas, so as to improve energy utilization efficiency while ensuring lighting effect.
Environmental Adaptability: Factors such as road width, lamp pole height, installation spacing, road surface reflectivity and surrounding buildings should be considered. For example, narrow old urban lanes and wide urban arterial roads require completely different light distribution schemes.
2. Rational Selection of Secondary Optics Components: The Foundation of Matching Effect
The selection of secondary optics components (lenses and reflectors) directly affects the matching effect. Different components have their own characteristics and applicable scenarios, and it is necessary to select and combine them according to the actual needs.
2.1 Lenses: The Main Choice for Precise Light Control
Lenses are the most commonly used secondary optics components in LED street lights, which realize light redistribution through refraction. According to the structural design, they can be divided into the following types:
Total Internal Reflection (TIR) Lenses: Based on the principle of total internal reflection, when light is emitted from an optically denser medium to an optically rarer medium and the incident angle is greater than the critical angle, total internal reflection occurs, which can effectively collect and redirect the scattered light of LEDs. Its advantages are high light utilization efficiency (up to 90% or more), uniform light distribution and compact structure. It is suitable for medium and high-power LED street lights, and can adjust the beam angle within ±30° to meet the basic light distribution needs.
Free-Form Surface Lenses: This is a high-precision optical component designed with asymmetric rectangular light distribution in X and Y axes. It can realize customized light distribution according to specific road needs. For example, it can produce uniform light distribution of ±60° in the X axis (meeting the lighting requirements of the road length direction) and ±30° in the Y axis, forming the "batwing" light distribution suitable for road lighting. Its advantages are strong customization, perfect adaptation to different road widths and shapes, and good glare control effect. It is the first choice for high-end LED street lights and special road sections (such as ramps and intersections). The design of free-form surface lenses usually adopts methods such as differential equation method and multi-parameter optimization to match the light distribution of the light source with the target lighting surface.
Array Lenses: Composed of multiple small lenses, it is suitable for LED street lights with multi-chip array layout. Each small lens corresponds to one LED chip, which can realize independent light control of each chip, and then integrate to form the required overall light distribution. Its advantages are flexible light distribution adjustment and good uniformity, which can avoid the problem of uneven light distribution caused by multi-chip arrangement. It is suitable for large-power LED street lights composed of 1W to several watts of LED chips in array series-parallel connection.
When selecting lenses, in addition to considering the beam angle and light distribution type, attention should also be paid to the material. PC (polycarbonate) and PMMA (polymethyl methacrylate) are the most commonly used materials. PC has good impact resistance and high temperature resistance, suitable for outdoor harsh environments; PMMA has higher light transmittance (>92%), but poor impact resistance, suitable for relatively stable installation environments.
2.2 Reflectors: Supplementary Role for Light Distribution Optimization
Reflectors realize light redistribution through reflection, which is often used in combination with lenses to make up for the defects of single lens light distribution. According to the surface shape, they can be divided into parabolic reflectors, elliptical reflectors and irregular reflectors:
Parabolic Reflectors: They can converge the scattered light of LEDs into parallel light, which has strong long-distance irradiation capacity. It is suitable for road sections that need long-distance lighting (such as urban arterial roads and expressways), but the light distribution uniformity is relatively poor, so it is usually used in combination with lenses to balance the irradiation distance and uniformity.
Irregular Reflectors: Designed according to the required light distribution curve, they can realize asymmetric light distribution and are suitable for road sections with special lighting needs (such as sidewalks adjacent to roads and road intersections). They can effectively collect the light scattered to the side and redirect it to the target area, improving light utilization efficiency.
The key to selecting reflectors is the reflection efficiency. It is recommended to choose materials with high reflectivity (such as aluminum alloy with anodized treatment, reflectivity up to 85% or more) to reduce light loss. At the same time, attention should be paid to the surface smoothness to avoid uneven light distribution caused by rough surfaces.
3. Scientific Matching of Light Distribution Schemes: Adapt to Different Road Scenarios
The core of secondary optics matching is to formulate a scientific light distribution scheme according to the road scenario. The key lies in matching the light distribution type (TYPE1/TYPE2/TYPE3) and cut-off type, and combining the lens and reflector reasonably to achieve the optimal lighting effect.
3.1 Matching Based on Road Width and Lamp Pole Height
The international general TYPE1/TYPE2/TYPE3 light distribution classification is the core basis for matching, which is determined by the ratio of "irradiation width to lamp pole height":
Narrow Roads (Sidewalks, Old Urban Lanes): Choose TYPE1 light distribution matching full cut-off type. TYPE1 light distribution is symmetric, with the irradiation width approximately equal to the lamp pole height (e.g., a 10-meter high lamp irradiates 10 meters wide), and the light is concentrated directly below, without spreading to both sides. Matching with full cut-off lenses or reflectors can strictly control the light within 65° downward, avoiding glare and light pollution to nearby residents, which is in line with the lighting needs of narrow roads and residential areas.
Medium Width Roads (Non-motor Vehicle Lanes, Community Main Roads): Choose TYPE2 light distribution matching semi-cut-off type. TYPE2 light distribution has a slightly wider irradiation range, covering 1.5-2 times the lamp pole height (e.g., a 10-meter high lamp irradiates 15-20 meters wide), with light slightly offset to one side, balancing uniformity and coverage area. Semi-cut-off type allows a small amount of horizontal light, with the light intensity at 90° direction ≤50cd/1000lm and 80° direction ≤100cd/1000lm, which is suitable for daily lighting of medium width roads and can avoid affecting the rest of surrounding residents while ensuring lighting effect.
Wide Roads (Urban Arterial Roads, Parking Lots): Choose TYPE3 light distribution matching semi-cut-off type. TYPE3 light distribution has the widest irradiation range, covering about 2.75 times the lamp pole height (e.g., a 10-meter high lamp irradiates about 27.5 meters wide), with strong horizontal coverage capacity, suitable for long-distance continuous lighting. Matching with free-form surface lenses and parabolic reflectors can realize long-distance irradiation and uniform light distribution, meet the lighting needs of motor vehicle traffic, and at the same time control glare through semi-cut-off design.
3.2 Matching Based on Light Distribution Curve
The light distribution curve of LED street lights directly determines the lighting effect. The most suitable light distribution curve for road lighting is the "batwing" curve, which has high light intensity in the middle and low light intensity at the edges, avoiding excessive brightness in the center and dark areas at the edges, and effectively improving the uniformity of road surface illuminance. In the process of secondary optics matching, the following points should be noted:
For roads that need uniform lighting (such as urban arterial roads), choose lenses or reflectors that can generate "batwing" light distribution to ensure that the illuminance difference between the center and the edge of the road is within a reasonable range;
For special road sections (such as road intersections and ramps), adopt asymmetric light distribution design to focus the light on the key area (such as the intersection center) and avoid light waste;
Use professional optical simulation software (such as DIALux, ASAP) to simulate the light distribution effect in advance, adjust the parameters of lenses and reflectors according to the simulation results, and ensure that the light distribution curve meets the design requirements.
3.3 Matching with LED Light Source Characteristics
The secondary optics matching should be closely combined with the characteristics of LED light sources (luminous angle, luminous flux, color temperature, etc.) to avoid mismatching between the light source and optical components, resulting in reduced light utilization efficiency and poor lighting effect:
For LEDs with a large luminous angle (120°-140°), TIR lenses or free-form surface lenses should be selected to collect scattered light and improve light utilization efficiency; for LEDs with a small luminous angle, reflectors can be used to expand the irradiation range;
The color temperature of LED street lights is usually 3000K-5000K. For residential areas and sidewalks, warm white light (3000K-4000K) is recommended to reduce glare and improve visual comfort; for urban arterial roads and expressways, neutral white light (4000K-5000K) is recommended to improve the recognition of road signs and obstacles;
For multi-chip LED street lights, array lenses should be selected to realize independent light control of each chip, avoid uneven light distribution caused by mutual interference between chips, and ensure the overall lighting uniformity.
4. Avoid Common Matching Mistakes: Ensure Stable Performance
In the actual secondary optics matching process, many engineering and design personnel will have some mistakes, which affect the lighting effect and service life of LED street lights. The common mistakes and avoidance methods are as follows:
Blindly Pursuing Small Beam Angle: Some people think that a smaller beam angle can improve the irradiation distance, but ignoring the uniformity. For wide roads, a too small beam angle will lead to narrow irradiation range and dark areas between adjacent street lights; for narrow roads, a too large beam angle will cause light waste and glare. The beam angle should be selected according to the road width and lamp pole height, usually 60°-120°.
Ignoring the Combination of Lenses and Reflectors: Blindly using a single lens or reflector will have limitations. For example, a single lens has poor long-distance irradiation capacity, and a single reflector has poor uniformity. The combination of the two can complement each other and achieve the balance between irradiation distance and uniformity.
Neglecting Glare Control: Only focusing on illuminance and ignoring glare control will affect the visual comfort of drivers and pedestrians. In the matching process, appropriate cut-off type should be selected, and the surface of optical components should be treated (such as frosted treatment) to reduce glare.
Ignoring the Influence of Environmental Factors: Not considering the road surface reflectivity, surrounding buildings and other factors will lead to inconsistent actual lighting effect with the design. For example, the light reflection effect of light-colored road surfaces (reflectivity 0.3-0.4) is better than that of dark-colored road surfaces, and the light distribution parameters can be appropriately adjusted according to the road surface color.
5. Post-installation Debugging and Maintenance: Ensure Long-term Stable Matching Effect
The secondary optics matching of LED street lights is not a one-time work. Post-installation debugging and regular maintenance are needed to ensure that the matching effect remains stable for a long time:
On-site Debugging: After the installation of street lights, use professional illuminance meters to detect the road surface illuminance and uniformity, adjust the installation angle of street lights and the parameters of optical components according to the detection results, and ensure that the lighting effect meets the design requirements. For example, adjust the cantilever length (0.5-1.5 meters) to improve the illuminance uniformity of sidewalks, and adjust the lamp pole spacing (usually 3-4 times the installation height) to avoid dark areas.
Regular Cleaning: The surface of lenses and reflectors will accumulate dust, dirt and other impurities over time, which will reduce light transmittance and reflection efficiency, and affect the matching effect. It is recommended to clean the optical components regularly (once every 3-6 months) to ensure their surface cleanliness.
Regular Inspection: Regularly inspect the optical components for damage, deformation, aging and other phenomena. If any problem is found, replace them in time to avoid affecting the overall lighting effect. At the same time, check the LED light source for light decay (replace it when the light decay is more than 30%) to ensure the matching stability between the light source and optical components.
Conclusion
The secondary optics matching of LED street lights is a systematic project that integrates optical design, component selection, scene adaptation and post-maintenance. Its core is to take the road lighting requirements as the guide, select appropriate optical components, formulate scientific light distribution schemes, and realize the balance between high lighting quality, high energy utilization efficiency and low glare. With the continuous development of LED technology and optical design technology, the secondary optics matching technology of LED street lights will be more mature and intelligent, such as adaptive optical systems that can automatically adjust light distribution according to real-time traffic conditions.
For Google website editors, engineers and related practitioners, mastering the above secondary optics matching skills can not only improve the lighting quality of LED street lights, reduce energy consumption and maintenance costs, but also promote the healthy development of the LED lighting industry and contribute to the construction of energy-saving and environment-friendly cities. In the future, we should continue to pay attention to the innovation of optical components and design methods, and continuously optimize the secondary optics matching scheme to meet the increasingly diverse road lighting needs.
